约翰迪尔零件查询1200 - AXLE RE37211 INBOARD PLANETARY FINAL DRIVE (OC-4)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
594 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R33022
|
[6] |
Thrust Washer
|
|
| 2. |
R33028
|
[99] |
Needle Roller
|
|
| 3. |
R33004
|
[3] |
Pinion
|
|
| 4. |
R63112
|
[3] |
Pinion Shaft
|
|
| 5. |
R33029
|
[1] |
Snap Ring
|
|
| 6. |
R82917
|
[1] |
Planet Pinion Carrier
|
|
| 7. |
R61461
|
[AR] |
Shim
|
|
| 7. |
R59439
|
[AR] |
Shim
|
|
| 7. |
R59440
|
[AR] |
Shim
|
|
| 7. |
R79989
|
[AR] |
Shim
|
|
| 8. |
F2380R
|
[1] |
Washer
|
|
| 9. |
R48437
|
[1] |
Shim
|
|
| 10. |
R82918
|
[1] |
Spacer
|
|
| 11. |
R82175
|
[1] |
Cap Screw
|
|
| 12. |
R26012
|
[1] |
Lock Plate
|
|
| 13. |
B152R
|
[1] |
Snap Ring
|
|
| 14. |
R48431
|
[1] |
Pinion
|
|
| 15. |
R48432
|
[1] |
Drive Shaft
|
|
