约翰迪尔零件查询1200 - AXLE RE37214 INBOARD PLANETARY FINAL DRIVE (OC-7)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
833 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R56290
|
[6] |
Thrust Washer
|
|
| 2. |
R35003
|
[99] |
Needle Roller
|
|
| 3. |
R57053
|
[3] |
Pinion
|
|
| 4. |
R92826
|
[3] |
Pinion Shaft
|
|
| 5. |
R57055
|
[1] |
Snap Ring
|
|
| 6. |
R82922
|
[1] |
Planet Pinion Carrier
|
|
| 7. |
F2380R
|
[1] |
Washer
|
|
| 8. |
R61461
|
[AR] |
Shim
|
|
| 8. |
R59439
|
[AR] |
Shim
|
|
| 8. |
R59440
|
[AR] |
Shim
|
|
| 8. |
R79989
|
[AR] |
Shim
|
|
| 9. |
R52389
|
[1] |
Shim
|
|
| 10. |
R82921
|
[1] |
Washer
|
|
| 11. |
R82175
|
[1] |
Cap Screw
|
|
| 12. |
R26012
|
[1] |
Lock Plate
|
|
| 13. |
R36664
|
[1] |
Snap Ring
|
|
| 14. |
R57052
|
[1] |
Gear
|
|
| 15. |
R73013
|
[1] |
Drive Shaft
|
|
