约翰迪尔零件查询1200 - AXLE RE38197 STANDARD DIFFERENTIAL(OC-1)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
633 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R68187
|
[8] |
Bolt
|
|
| 2. |
R47172
|
[8] |
Washer
|
|
| 3. |
R109006
|
[1] |
Thrust Washer
|
|
| 4. |
R63240
|
[1] |
Cover
|
|
| 5. |
R63347
|
[2] |
Bevel Gear
|
|
| 6. |
R63341
|
[4] |
Thrust Washer
|
|
| 6. |
R112769
|
[4] |
Thrust Washer
|
|
| 7. |
R70040
|
[4] |
Pinion
|
|
| 7. |
R120349
|
[4] |
Pinion
|
|
| 8. |
R70038
|
[2] |
Pinion Shaft
|
|
| 9. |
B1402R
|
[4] |
Snap Ring
|
|
| 10. |
R70042
|
[4] |
Thrust Washer
|
|
| 11. |
R70041
|
[104] |
Needle Roller
|
|
| 12. |
R70039
|
[4] |
Thrust Washer
|
|
| 14. |
R63162
|
[1] |
Housing
|
|
| 15. |
R135543
|
[12] |
Washer
|
|
| 16. |
19H2672
|
[12] |
Cap Screw
|
|
