约翰迪尔零件查询1200 - AXLE RE38195,RE38196,RE38198 DIFFERENTIAL LOCK (OC-3)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
618 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R115437
|
[12] |
Cap Screw
|
|
| 2. |
R47172
|
[12] |
Washer
|
|
| 3. |
R1901R
|
[3] |
Spring
|
|
| 4. |
34H385
|
[3] |
Spring Pin
|
|
| 6. |
RE36863
|
[1] |
Cover
|
|
| 10. |
R67045
|
[1] |
Piston
|
|
| 11. |
R67047
|
[1] |
Washer
|
|
| 12. |
R67046
|
[1] |
Washer
|
|
| 13. |
AR87164
|
[1] |
Housing
|
|
| 14. |
19H2672
|
[12] |
Cap Screw
|
|
| 15. |
R135543
|
[12] |
Washer
|
|
| 16. |
R63340
|
[1] |
Bevel Gear
|
|
| 26. |
400R
|
[2] |
Ball
|
|
| 27. |
AR101124
|
[1] |
Housing
|
|
| 28. |
R60038
|
[1] |
Packing
|
|
| 29. |
YZ120909
|
[1] |
Spring Pin
|
|
| 30. |
R47172
|
[8] |
Washer
|
|
