| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | R89835 | [1] | Spindle | |
| 2. | RE33442 | [1] | Seal | |
| 3. | R106854 | [1] | Oil Cup | (SUB FOR R93966) |
| 4. | JD9033 | [1] | Bearing Cone | |
| 5. | JD8297 | [1] | Bearing Cup | |
| 6. | 15H559 | [1] | Pipe Plug | 1/4" |
| 10. | AR78412 | [1] | Seal | |
| 11. | JD9127 | [1] | Bearing Cup | |
| 12. | JD9069 | [1] | Bearing Cone | |
| 13. | R63237 | [1] | Shim | |
| 14. | R63246 | [AR] | Shim | 0.51MM (.020") |
| 14. | R63247 | [AR] | Shim | 0.13MM (.005") |
| 14. | R63248 | [AR] | Shim | 0.18MM (.007") |
| 15. | R33330 | [1] | Washer |
