约翰迪尔零件查询RE160302 - AXLE AXLE OIL RECIRCULATION PUMP AND MOTOREPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
334 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T77613
|
[3] |
O-Ring
|
|
| 2. |
T77857
|
[3] |
O-Ring
|
|
| 3. |
38H1005
|
[1] |
Elbow Fitting
|
|
| 4. |
38H1160
|
[1] |
Adapter Fitting
|
|
| 5. |
R26448
|
[1] |
O-Ring
|
|
| 6. |
19M7868
|
[4] |
Screw
|
|
| 7. |
AT220832
|
[1] |
Pump
|
|
| 8. |
R26906
|
[2] |
O-Ring
|
|
| 9. |
38H1174
|
[1] |
Adapter Fitting
|
|
| 10. |
38H1012
|
[1] |
Elbow Fitting
|
|
| 11. |
19M7950
|
[2] |
Cap Screw
|
|
| 12. |
24M7242
|
[2] |
Washer
|
|
| 13. |
14M7396
|
[4] |
Lock Nut
|
|
| 14. |
T197061
|
[1] |
Bracket
|
|
| 15. |
R26375
|
[4] |
O-Ring
|
|
| 16. |
38H1010
|
[2] |
Elbow Fitting
|
|
| 17. |
AT223728
|
[1] |
Control Valve
|
|
| 17. |
AT223805
|
[1] |
Seal Kit
|
|
