约翰迪尔零件查询1400 - AXLE SECONDARY STEERING KIT (TORQUE CONVERTER) (FIELD)EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 723 次

Pos.	Part No	Qty	Parts name	Comments
1.	14M7296	[1]	Flange Nut	M10
2.	14M7524	[4]	Flange Nut	M8
3.	19M7785	[3]	Screw	M10 X 25
4.	19M7812	[2]	Screw	M10 X 100
5.	19M7867	[4]	Screw	M8 X 25
6.	19M8162	[3]	Screw	M10 X 40
7.	24M7296	[3]	Washer	10.500 X 30 X 2.500 MM
8.	28H3389	[1]	Spacer	0.423" X 0.675" X 1"
9.	57M7689	[1]	Fuse
10.	38H1095	[1]	Elbow Fitting	(SUB FOR 38H1003)
11.	R28782	[1]	O-Ring	8.915 X 1.829 MM (0.351" X 0.072")
12.	T77814	[1]	O-Ring	7.650 X 1.780 MM (0.301" X 0.070")
13.	38H1013	[1]	Elbow Fitting
14.	T77857	[1]	O-Ring	12.421 X 1.778 MM (0.489" X 0.070")
15.	U12547	[1]	O-Ring	23.470 X 2.946 MM (0.924" X 0.116")
16.	38H1029	[1]	Tee Fitting
17.	38H1096	[1]	Elbow Fitting
18.	T77932	[3]	O-Ring	15.596 X 1.778 MM (0.614" X 0.070")
19.	38H1164	[1]	Adapter Fitting
20.	R29936	[1]	O-Ring	29.743 X 2.946 MM (1.171" X 0.116")
21.	T76938	[1]	O-Ring	23.520 X 1.780 MM (0.926" X 0.070")
22.	38H1329	[1]	Adapter Fitting
23.	38H1179	[1]	Adapter Fitting	(SUB FOR 38H1431)
24.	38H1447	[1]	Adapter Fitting
25.	AT117264	[1]	Switch
26.	AT141527	[1]	Check Valve	(INCLUDES R26375 AND T77857)
26.	R26375	[1]	O-Ring	16.358 X 2.210 MM (0.644" X 0.087")
26.	T77857	[1]	O-Ring	12.421 X 1.778 MM (0.489" X 0.070")
27.	AT183657	[1]	Hydraulic Hose - Fabricate	1" X 263 MM (10-1/2") X 1"
28.	AT223648	[1]	Fitting
29.	R51031	[1]	Fitting
30.	AT317957	[1]	Hydraulic Hose - Fabricate	13/16" X 890 MM (35") X 13/16"
31.	AT317958	[1]	Hydraulic Hose - Fabricate	9/16" X 689 MM (27-1/4") X 9/16"
32.	AT317959	[1]	Hydraulic Hose - Fabricate	13/16" X 1172 MM (46-1/4") X 1"
33.	AT344580	[1]	Pump
34.	AT345320	[1]	Hydraulic Motor
34.	AT345719	[1]	Seal Kit
36.	AT345721	[1]	Pump
37.	AT345722	[1]	Switch
38.	AT345723	[1]	Pressure Relief Valve
38.	AT170991	[1]	O-Ring Kit
42.	AT345505	[1]	Wiring Harness
43.	AT347144	[1]	Hydraulic Hose - Fabricate	36.5252" X 1270 MM (50") X 36.5252"
44.	H77698	[2]	Tie Band
45.	N189220	[1]	Tie Band
46.	R26375	[1]	O-Ring	16.358 X 2.210 MM (0.644" X 0.087")
48.	R76477	[1]	Tie Band
49.	RE15428	[1]	Timer
50.	12H379	[4]	Lock Washer	0.164"
51.	14H1072	[8]	Nut	0.164"
52.	T102934	[1]	Clamp
53.	T146443	[1]	Safety Sign
54.	T150265	[1]	Plate
55.	T163583	[1]	Strap
56.	T163655	[1]	Bracket
57.	T235366	[1]	Plate	(SUB FOR T235366)
58.	U42208	[3]	Isolator
60.	AT346563	[1]	Field Installation Kit
