约翰迪尔零件查询1400 - AXLE SERVICE BRAKE ACCUMULATOR AND LINES (DIRECT DRIVE)EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
688 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT133354
|
[1] |
Manual Hydraulic Valve
|
|
| 1. |
AT147077
|
[1] |
Seal Kit
|
|
| 1. |
AT329753
|
[1] |
Manual Hydraulic Valve
|
|
| 1. |
AT325225
|
[1] |
Seal Kit
|
|
| 3. |
AT156938
|
[1] |
Pressure Switch
|
|
| 4. |
R28782
|
[1] |
O-Ring
|
|
| 5. |
19M7657
|
[2] |
Screw
|
|
| 6. |
38H1045
|
[1] |
Elbow Fitting
|
|
| 7. |
R26448
|
[4] |
O-Ring
|
|
| 8. |
T77613
|
[7] |
O-Ring
|
|
| 9. |
38H1160
|
[2] |
Adapter Fitting
|
|
| 10. |
38H1173
|
[1] |
Adapter Fitting
|
|
| 10. |
38H1161
|
[1] |
Adapter Fitting
|
|
| 11. |
T77857
|
[1] |
O-Ring
|
|
| 12. |
38H1285
|
[1] |
Union Fitting
|
|
| 13. |
R44302
|
[8] |
Tie Band
|
|
| 14. |
T81029
|
[1] |
Nut
|
|
| 15. |
AT332254
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 16. |
AT180372
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 17. |
AT180611
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 18. |
AT318080
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 19. |
AT313974
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 20. |
AT181524
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 21. |
AT332439
|
[1] |
Hydraulic Accumulator
|
|
| 21. |
T155572
|
[1] |
Safety Sign
|
|
| 21. |
T155579
|
[1] |
Safety Sign
|
|
| 21. |
T155580
|
[1] |
Safety Sign
|
|
| 21. |
T155581
|
[1] |
Safety Sign
|
|
| 22. |
AT326636
|
[1] |
Check Valve
|
|
| 23. |
T101975
|
[1] |
Bushing
|
|
| 24. |
T126204
|
[2] |
Clamp
|
|
| 25. |
14M7400
|
[2] |
Lock Nut
|
|
| 26. |
19M7807
|
[1] |
Screw
|
|
| 27. |
19M7810
|
[1] |
Screw
|
|
| 28. |
28H3389
|
[1] |
Spacer
|
|
| 29. |
38H1030
|
[1] |
Tee Fitting
|
|
