| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T162749 | [1] | Pedal | |
| 2. | T162273 | [1] | Shaft | |
| 3. | T163218 | [1] | Extension Spring | |
| 3. | N204981 | [1] | Compression Spring | |
| 4. | T202658 | [2] | Bushing | |
| 5. | AT188943 | [1] | Bracket | |
| 6. | E63018 | [1] | Spring Pin | |
| 7. | 14M7298 | [1] | Flange Nut | M8 |
| 8. | 19M7165 | [1] | Cap Screw | M8 X 55 |
| 9. | 19M7866 | [3] | Screw | M8 X 20 |
