| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T56112 | [2] | Elbow Fitting | 3.175 MM (1/8") |
| 2. | AT53932 | [2] | Hydraulic Hose | 1/8" X 804 MM (31-3/4") X 1/8" |
| 3. | R36311 | [5] | Fitting | |
| 4. | E12379 | [6] | Nut | 3.175 MM (1/8") |
| 5. | JD7797 | [5] | Lubrication Fitting | |
| 6. | AT64886 | [1] | Hydraulic Hose | 1/8" X 1739 MM (68-1/2") X 1/8" |
| 7. | R53014 | [1] | Fitting | 3.175 MM (1/8") |
| 8. | AT66124 | [1] | Hose | 1/8" X 2794 MM (110") X 1/8" |
| 9. | AT53541 | [1] | Hydraulic Hose | 1/8" X 1489 MM (58-3/4") X 1/8" |
| 10. | T36210 | [1] | Grommet | |
| 11. | R44302 | [6] | Tie Band | (NOT ILLUSTRATED) |
