约翰迪尔零件查询1400 - AXLE CABLE ROLLERS (CABLE SKIDDER)EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 156 次

Pos.	Part No	Qty	Parts name	Comments
1.	14M7277	[16]	Nut	M20
2.	14M7400	[1]	Lock Nut	M10
3.	19M7811	[1]	Screw	M10 X 90
4.	19M8002	[8]	Cap Screw	M20 X 55
5.	19M8011	[2]	Cap Screw	M12 X 30
6.	19M8639	[4]	Cap Screw	M20 X 70
7.	24H1480	[4]	Washer	1-5/32" X 2" X 0.060"
8.	24M7180	[2]	Washer	13 X 37 X 3 MM
9.	24M7242	[32]	Washer	21.400 X 42 X 5 MM
10.	28H3421	[2]	Spacer	0.493" X 0.675" X 7/16"
11.	AT168957	[2]	Pin
12.	AT193138	[1]	Support
13.	AT193139	[1]	Support
14.	AT193141	[2]	Roller	(INCLUDES T308138)
14.	T308138	[1]	Roller
15.	T132057	[2]	Bushing
16.	AT193140	[1]	Roller	(STANDARD ROLLER) (CONVENIENCE ASSEMBLY)
17.	T185659	[2]	Bushing
18.	JD7797	[6]	Lubrication Fitting
19.	N2445W	[4]	Washer	29.362 X 53.848 X 6.350 MM (1-5/32" X 2.120" X 1/4")
20.	T153416	[1]	Pin
21.	T186643	[1]	Support
22.	T186644	[1]	Support
23.	T39569	[4]	Washer	45.240 X 88.900 X 3.302 MM (1-25/32" X 3-1/2" X 0.130")
24.	19M7892	[4]	Cap Screw	M20 X 80
