久保田零件查询K13500 MOWER CONTROL DIAL TOP LINK/TOP LINK BRACKET/PTO PROTECTOREPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
123 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
K258144410
|
[1] |
CAM
|
1.1550(lbs); 0.525
|
| 020. |
K258144422
|
[1] |
ROD,CAM
|
0.3828(lbs); 0.174
|
| 030. |
0277150100
|
[1] |
NUT,FLANGE
|
0.0110(lbs); 0.005
|
| 040. |
0401350120
|
[1] |
WASHER,PLAIN
|
0.0154(lbs); 0.007
|
| 050. |
K258144430
|
[1] |
DIAL,CAM
|
0.0660(lbs); 0.030
|
| 060. |
K258144440
|
[1] |
PLATE,RETAINER
|
0.0220(lbs); 0.010
|
| 070. |
K112291332
|
[1] |
BOLT(SHORT SQ. NECK,M8 1.25)
|
0.0330(lbs); 0.015
|
| 080. |
0275150080
|
[1] |
NUT,FLANGE
|
0.0132(lbs); 0.006
|
