约翰迪尔零件查询850 - BACKHOE Dipperstick CylinderEPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
147 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
JD7842
|
[2] |
Lubrication Fitting
|
|
| 2. |
AT326492
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 3. |
M121932
|
[1] |
Nut
|
|
| 4. |
........
|
[1] |
Wear Ring
|
|
| 5. |
........
|
[1] |
Seal
|
|
| 6. |
........
|
[1] |
O-Ring
|
|
| 7. |
M121931
|
[1] |
Piston
|
|
| 8. |
........
|
[1] |
Wear Ring
|
|
| 9. |
........
|
[1] |
Seal
|
|
| 10. |
........
|
[1] |
Seal
|
|
| 11. |
........
|
[1] |
O-Ring
|
|
| 12. |
........
|
[1] |
Back-Up Ring
|
|
| 13. |
M121930
|
[1] |
Packing
|
|
| 14. |
........
|
[1] |
Plug
|
|
| 15. |
........
|
[1] |
Seal
|
|
| 16. |
AT326493
|
[1] |
Rod
|
|
| 17. |
M121927
|
[4] |
Rod
|
|
| 18. |
AT326468
|
[1] |
Hydraulic Cylinder
|
|
| ... |
AM121001
|
[1] |
Seal Kit
|
|
