| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | LVA11352 | [1] | Tube | |
| 2. | PT10406 | [1] | Lock Nut | (A) |
| 3. | M138574 | [1] | Piston | |
| 4. | ........ | [1] | Wear Ring | (A) |
| 5. | ........ | [1] | Seal | (A) WIPER |
| 6. | ........ | [1] | Seal | (A) U-CUP |
| 7. | ........ | [1] | O-Ring | (A) |
| 8. | ........ | [1] | Back-Up Ring | (A) |
| 9. | AM127936 | [1] | Seal | ROD |
| 10. | ........ | [1] | Seal | (A) WIPER |
| 11. | LVU12342 | [1] | Rod | |
| 12. | M138580 | [1] | Bearing | |
| 13. | AM127938 | [1] | Seal Kit | INCLUDES PARTS MARKED (A) |
| 14. | LVA11306 | [1] | Hydraulic Cylinder | BLACK PAINT |
