| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | KV16800 | [1] | Tube | |
| 2. | H29623 | [1] | Lock Nut | |
| 3. | M138575 | [1] | Piston | |
| 4. | ........ | [1] | O-Ring | |
| 5. | ........ | [1] | Back-Up Ring | |
| 6. | ........ | [1] | O-Ring | |
| 7. | ........ | [1] | Back-Up Ring | |
| 8. | ........ | [1] | Seal | |
| 9. | ........ | [1] | Snap Ring | |
| 10. | AM127937 | [1] | Seal Kit | |
| 11. | PT10486 | [1] | Seal | |
| 12. | KV16801 | [1] | Hydraulic Cylinder Rod | |
| 13. | AM127899 | [1] | Hydraulic Cylinder | BLACK PAINT |
