约翰迪尔零件查询92 - BACKHOE MAST AND SWING LINKAGE [A12]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 150 次

Pos.	Part No	Qty	Parts name	Comments
1.	U40628	[1]	Pin
2.	19H3586	[2]	Cap Screw	1/2" X 4-1/4"
3.	BP12214	[4]	Lock Nut	1/2", (SUB FOR U12622)
4.	U40334	[1]	Pin Fastener
5.	11M7030	[1]	Cotter Pin	5 X 40 MM
6.	S2955DW	[1]	Pin
7.	U40362	[1]	Pin
8.	AU40184	[1]	Mast
9.	19H3170	[3]	Cap Screw	5/8" X 4-1/2"
10.	JD7759	[2]	Lubrication Fitting	STRAIGHT, 1/8"
11.	U40313	[2]	Pin	(USE WITH AT56437 MAIN FRAME)
12.	U40304	[1]	Bushing	(USE WITH AT56437 MAIN FRAME)
13.	AU40928	[1]	Quick Lock Pin	(SUB FOR AU40204) (USE WITH AT56437 MAIN FRAME)
14.	U40308	[4]	Bushing
15.	AU40189	[1]	Link	OUTER
16.	19H2855	[1]	Cap Screw	3/8" X 3-1/4"
17.	T11234	[1]	Lock Nut	3/8"
18.	U40314	[1]	Pin
19.	U40306	[2]	Bushing
20.	........	[2]	Bearing Cap	(SUB AU40187)
21.	AU40187	[1]	Clevis	INNER
22.	12H294	[4]	Lock Washer	5/8"
23.	19H2599	[4]	Cap Screw	5/8" X 2-1/2"
24.	JD7806	[3]	Lubrication Fitting	90°, 1/4"
25.	JD7797	[3]	Lubrication Fitting	STRAIGHT, 1/4"
26.	U40311	[1]	Pin	(ONE USED SWING LINK; ONE USED SWING CYLINDER)
27.	U40305	[1]	Bushing	LOWER (USE WITH AT56437 MAIN FRAME)
28.	U40312	[2]	Pin Fastener
29.	19H1868	[1]	Cap Screw	1/2" X 3-3/4"
30.	U44915	[3]	Lock Nut	5/8"
31.	19H3057	[1]	Cap Screw	1/2" X 2-3/4"
32.	12H301	[1]	Lock Washer	1/2"
33.	AU40727	[1]	Retainer
34.	19H1805	[1]	Cap Screw	1/2" X 2-1/4"
35.	24H1341	[1]	Washer	17/32" X 15/16" X 0.060"
36.	U10974	[1]	Bushing
37.	U41129	[1]	Bushing
