| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AU42103 | [1] | Quick Lock Pin | |
| 2. | U43220 | [1] | Bushing | SWING LOCK PIN |
| 3. | JD7806 | [2] | Lubrication Fitting | |
| 4. | U43212 | [2] | Bolt | |
| 5. | U43180 | [4] | Spacer | TAPERED PIN |
| 6. | U43179 | [4] | Tapered Sleeve | |
| 7. | U43208 | [2] | Pin | MAST TO MAIN FRAME |
| 8. | 19H2717 | [2] | Cap Screw | 3/4" X 1-3/4" |
| 9. | AT66323 | [1] | Kit | PIN (USE WHEN AU42092 HAS BEEN INSTALLED AS A REPLACEMENT PART) |
