约翰迪尔零件查询92 - BACKHOE SWING VALVE (CLOSED-CENTER HYDRAULIC SYSTEM) (SERIAL NO. 003301- ) [B06]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 338 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap
2.	U11428	[1]	Bolt
3.	N31767	[2]	Washer
4.	U11336	[1]	Spring
5.	U41167	[1]	Bushing
6.	U41162	[1]	Plug
7.	P46051	[2]	O-Ring
8.	U41170	[2]	Spring
9.	U41168	[2]	Check Valve
10.	........	[1]	Spool	(SUB AT34643)
11.	32240	[2]	O-Ring
12.	AU40529	[1]	Pressure Relief Valve	(2375 PSI)
13.	U40727	[2]	Back-Up Ring
14.	P47908	[2]	O-Ring
15.	........	[1]	Housing	SWING VALVE, (SUB AT34643)
16.	AU40753	[1]	Relief Valve	(1875 PSI)
17.	21H1206	[2]	Screw	1/4" X 5/16"
18.	U42827	[1]	Retainer
19.	U42834	[1]	Seal
20.	U42835	[1]	Washer
21.	U41172	[2]	Plunger
22.	N85304	[2]	Spring
23.	R394R	[2]	O-Ring	3/32" X 11/16" O.D.
24.	AN85149	[2]	Fitting	ASSEMBLY
25.	T57246	[1]	O-Ring	(SUB FOR B2762R, THIS APPLICATION)
26.	U42833	[1]	Clevis
27.	T13119	[1]	O-Ring	(SUB FOR T57245)
28.	U41169	[1]	Bushing
29.	AT34643	[1]	Spool Valve	SWING, COMPLETE, (SUB FOR AU41886)
...	AU12404	[1]	Kit	REPAIR PLUG OR RELIEF VALVE, (SUB FOR AU40973)
...	AU42191	[1]	Kit	REPAIR INDIVIDUAL VALVE
