约翰迪尔零件查询92 - BACKHOE CROWD VALVE (OPEN-CENTER HYDRAULIC SYSTEM) [B07]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
504 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
........
|
[1] |
Spool
|
|
| 2. |
AU40561
|
[2] |
Valve
|
|
| 3. |
U40962
|
[2] |
O-Ring
|
|
| 4. |
........
|
[1] |
Housing
|
|
| 5. |
T13119
|
[2] |
O-Ring
|
|
| 6. |
R28776
|
[1] |
O-Ring
|
|
| 7. |
U40971
|
[1] |
Sealing Ring
|
|
| 8. |
AU40606
|
[1] |
Plug
|
|
| 9. |
U40967
|
[1] |
Spring
|
|
| 10. |
U40958
|
[1] |
Bolt
|
|
| 11. |
21H993
|
[2] |
Screw
|
|
| 12. |
T107279
|
[1] |
Cap
|
|
| 13. |
U40955
|
[1] |
Plate
|
|
| 14. |
U40952
|
[2] |
Guide
|
|
| 15. |
U40964
|
[1] |
Washer
|
|
| 16. |
U40954
|
[1] |
Poppet
|
|
| 17. |
U40965
|
[1] |
Spring
|
|
| 18. |
32240
|
[1] |
O-Ring
|
|
| 19. |
U40953
|
[1] |
Exhaust Cap
|
|
| ... |
AU40618
|
[1] |
Seal Kit
|
|
| ... |
AU40549
|
[1] |
Valve
|
|
