Pos.	Part No	Qty	Parts name	Comments
1.	U11004	[6]	Pin Fastener
2.	11M7079	[6]	Cotter Pin	2.500 X 12 MM
3.	U40667	[2]	Link	CONNECTOR STABILIZER LEVER (FOR 1010 ONLY)
3.	U41085	[2]	Link	CONNECTOR, STABILIZER LEVER (FOR JD300 AND JD400)
4.	34H339	[2]	Spring Pin	5/16" X 3/4"
5.	11M7083	[2]	Cotter Pin	3.200 X 50 MM
6.	T53976	[2]	Support	(SUB FOR U15803)
7.	14H826	[4]	Nut	1/2"
8.	U43216	[2]	Lever
9.	U43703	[4]	Grip
10.	U43214	[2]	Lever	(FOUR-WAY)
11.	34H330	[8]	Spring Pin	5/16" X 1-3/8"
12.	U40663	[2]	Link	OUTER VALVE CONTROL (1010 ONLY)
12.	U41084	[2]	Link	OUTER VALVE CONTROL (JD300 AND JD400)
13.	U11003	[4]	Pivot
14.	U10897	[2]	Support	HANDLE, FOUR-WAY LEVER
15.	U11001	[2]	Pin
16.	11M7059	[2]	Cotter Pin	3.200 X 20 MM
17.	14H821	[2]	Nut	5/8"
18.	U10995	[2]	Lever
19.	14H826	[2]	Nut	1/2"
20.	M884T	[2]	Grip
21.	U10895	[2]	Pivot
22.	U15804	[1]	Frame
23.	U16010	[2]	Pin Fastener
24.	19H2633	[4]	Cap Screw	3/8" X 1-1/2", (FOR JD300 AND JD400)
24.	19H3065	[4]	Cap Screw	3/8" X 2", (FOR 1010 ONLY)
25.	U11000	[2]	Pin Fastener
26.	U40664	[2]	Link	INNER VALVE CONTROL (FOR 1010 ONLY)
26.	U41084	[2]	Link	INNER VALVE CONTROL (FOR JD300 AND JD400)
27.	24H1274	[6]	Washer	49/64" X 1-1/4" X 0.048"
28.	U16056	[2]	Lever
29.	14H849	[2]	Nut	7/16"
30.	T10342	[2]	Knob
31.	U40666	[2]	Strap	(FOR 1010 ONLY)
32.	24H1305	[4]	Washer	13/32" X 13/16" X 0.065"
33.	12H304	[4]	Lock Washer	3/8"
