| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U40972 | [1] | Nut | LOCKING |
| 2. | U40959 | [1] | Screw | |
| 3. | A3190R | [2] | O-Ring | |
| 4. | U40966 | [1] | Spring | |
| 5. | U40960 | [1] | Plunger | |
| 6. | R31136 | [1] | Back-Up Ring | (SUB FOR U40963) |
| 7. | R10093 | [1] | O-Ring | |
| 8. | AU40609 | [1] | Seat | (INCLUDES SNUBBER) |
| 9. | AU40608 | [1] | Pressure Relief Valve | BODY AND POPPER ASSEMBLY |
| 10. | U40969 | [1] | Washer | |
| ... | AU40607 | [1] | Relief Valve | (2250 PSI) |
