约翰迪尔零件查询92 - BACKHOE CIRCUIT RELIEF VALVES FOR OPEN-CENTER HYDRAULIC SYSTEM [B11]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
964 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
14H1006
|
[1] |
Nut
|
|
| 2. |
........
|
[1] |
Set Screw
|
|
| 3. |
U40968
|
[2] |
Shim
|
|
| 4. |
14H774
|
[1] |
Nut
|
|
| 5. |
........
|
[1] |
Retainer
|
|
| 6. |
R28776
|
[1] |
O-Ring
|
|
| 7. |
U40971
|
[1] |
Sealing Ring
|
|
| 8. |
........
|
[1] |
Spring
|
|
| 9. |
........
|
[1] |
Seat
|
|
| 10. |
........
|
[1] |
Poppet
|
|
| 11. |
U40962
|
[1] |
O-Ring
|
|
| ... |
AU40565
|
[1] |
Valve
|
|
| ... |
AU40566
|
[1] |
Valve
|
|
| ... |
AU40564
|
[1] |
Valve
|
|
| ... |
AU40561
|
[1] |
Valve
|
|
