约翰迪尔零件查询92 - BACKHOE HEAVY-DUTY BUCKETS (WITH STRAIGHT PIVOT PLATES) [B22]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 980 次

Pos.	Part No	Qty	Parts name	Comments
1.	Y1951CU	[1]	Bushing
2.	U10699	[4]	Bushing
3.	U11651	[2]	Washer
4.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
5A.	AU11365	[1]	Pin Fastener
5B.	T59462	[1]	Pin Fastener	(SUB AU11365)
6.	28H2239	[1]	Spacer	1/1-4" X 7"
7.	AU12204	[1]	Plate	R.H. WITH BUSHINGS
8A.	AU11366	[1]	Pin Fastener
8B.	T59458	[1]	Pin Fastener	(SUB AU11366)
9.	U11649	[2]	Washer
10.	10H1034	[6]	Bolt	1/2" X 1-3/4"
10.	12H301	[6]	Lock Washer	1/2"
10.	14H826	[6]	Nut	1/2"
11.	24H1162	[6]	Washer	17/32" X 1-1/4" X 0.060"
12.	AU12234	[1]	Cutting Edge
13.	........	[1]	Backhoe Bucket	(A) ( BU10292 NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS)
13.	BU10293	[1]	Backhoe Bucket	(A) 24" (SUB AT37734 BUCKET AND ONE BU40403 BUCKET PINS)
14.	U13926	[1]	Cutting Edge	FRONT, FOR 18" H.D. BUCKET
14.	U13917	[1]	Cutting Edge	FRONT, FOR 24" H.D. BUCKET
15.	U13928	[1]	Shank	BUCKET TOOTH
16.	T40910	[1]	Pin	(SUB FOR U13927)
17.	U13929	[1]	Point	TIP
18.	AU12235	[1]	Cutting Edge	SIDE, L.H.
19.	AU12205	[1]	Plate	L.H. WITH BUSHINGS
20.	T59447	[2]	Snap Ring
21.	T59452	[2]	Snap Ring
