约翰迪尔零件查询92 - BACKHOE OIL LINES AND FITTINGS TO BOOM, CROWD AND BUCKET CYLINDERS FROM MANIFOLD [C10]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 218 次

Pos.	Part No	Qty	Parts name	Comments
1.	AW11540	[1]	Hydraulic Hose	1/2" X 66" (FOR 10-FOOT BACKHOE) (NO LONGER AVAILABLE)
1.	AU40400	[1]	Hydraulic Hose - Fabricate	1/2" X 73" (FOR 12-FOOT BACKHOE)
2.	AU10861	[2]	Hydraulic Hose - Fabricate	1/2" X 34", (SUB FOR AU11506)
3.	AU11849	[4]	Adapter	90°
4.	R26906	[5]	O-Ring
5.	AH16917	[3]	Adapter
6.	R26375	[3]	O-Ring
7.	15H666	[3]	Pipe Plug	3/8", (SUB FOR U40053, THIS APPLICATION)
8.	BP12232	[1]	Lock Nut	5/16"
9.	28H1636	[1]	Bushing	3/8" X 2-1/2"
10.	U13055	[1]	Clamp
11.	19H1921	[1]	Cap Screw	5/16" X 3-1/4"
12.	TY3009	[1]	Hydraulic Hose	1/2" X 36", (SUB FOR AU11762)
13.	AU40429	[1]	Hydraulic Hose - Fabricate	1/2" X 55"
14.	R26906	[3]	O-Ring
15.	AU11752	[1]	Fitting	90°
16.	U40643	[1]	Clamp
17.	AU40261	[1]	Hydraulic Hose - Fabricate	1/2" X 63-1/2" (FOR 10-FOOT BACKHOE)
17.	AU40399	[1]	Hydraulic Hose - Fabricate	1/2" X 76" (FOR 12-FOOT BACKHOE)
18.	AU40402	[1]	Line
19.	AU11753	[2]	Union Fitting
20.	U13055	[1]	Clamp
21.	R26906	[2]	O-Ring
22.	U11009	[2]	Adapter	45°
23.	AU40404	[1]	Tube	CROWD (FOR 10-FOOT BACKHOE)
23.	AU40492	[1]	Tube	CROWD (FOR 12-FOOT BACKHOE)
24.	AU40106	[1]	Tube	BUCKET
25.	AU12217	[1]	Adapter
26.	U11273	[1]	Elbow Fitting	45°
27.	AU11507	[2]	Hydraulic Hose - Fabricate	1/2" X 18-1/2" (FOR 10-FOOT BACKHOE)
27.	AW11013	[2]	Hydraulic Hose - Fabricate	1/2" X 24" (FOR 12-FOOT BACKHOE)
28.	T11234	[2]	Lock Nut	3/8"
29.	U40447	[1]	Clamp
30.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
31.	AU40405	[2]	Tube	(FOR 10-FOOT BACKHOE)
31.	AU40499	[2]	Tube	(FOR 12-FOOT BACKHOE)
32.	........	[1]	Clamp	( U40162 USE IF AVAILABLE)
33.	19H2664	[1]	Cap Screw	5/16" X 3/4"
33.	12H303	[1]	Lock Washer	5/16"
