约翰迪尔零件查询92 - BACKHOE SELECTOR VALVE WITH SYSTEM RELIEF VALVE USED ON 1010 WHEEL TRACTOR [C19]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
945 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U13099
|
[1] |
Handle
|
|
| 2. |
34H282
|
[1] |
Spring Pin
|
|
| 3. |
........
|
[1] |
Spool
|
|
| 4. |
U40729
|
[2] |
Back-Up Ring
|
|
| 5. |
32240
|
[3] |
O-Ring
|
|
| 6. |
........
|
[1] |
Housing
|
|
| 7. |
U13102
|
[1] |
Snap Ring
|
|
| 8. |
F3353R
|
[1] |
O-Ring
|
|
| 9. |
AU11768
|
[1] |
Plug
|
|
| 10. |
P47908
|
[1] |
O-Ring
|
|
| 11. |
U40727
|
[1] |
Back-Up Ring
|
|
| 12. |
AU40527
|
[1] |
Pressure Relief Valve
|
|
| 13. |
19H1907
|
[2] |
Cap Screw
|
|
| 13. |
12H303
|
[2] |
Lock Washer
|
|
| 13. |
14H785
|
[2] |
Nut
|
|
| 14. |
U13664
|
[1] |
Plate
|
|
| ... |
AU11766
|
[1] |
Selective Control Valve
|
|
