约翰迪尔零件查询9250 - BACKHOE SEAT (JD300, JD400, JD401-A WITH CANOPY) (JD350-B, JD450-B WITHOUT CANOPY) [C15]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 989 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2664	[4]	Cap Screw	5/16" X 3/4"
1.	12H303	[4]	Lock Washer	5/16"
2.	AU13546	[1]	Base	(JD300, JD400, JD401-A)
2.	AT33103	[1]	Support	(JD350-B, JD450-B)
3.	03H1524	[4]	Bolt	5/16" X 1"
3.	12H303	[4]	Lock Washer	5/16"
3.	14H785	[4]	Nut	5/16"
4.	U16005	[2]	Bushing
5.	24M7207	[4]	Washer	8.400 X 24 X 2 MM
6.	19H1849	[2]	Cap Screw	5/16" X 1-1/4"
6.	12H303	[2]	Lock Washer	5/16"
7.	T55118	[1]	Seat Back	(SUB FOR R34271) UPPER
8.	AT16820	[1]	Cushion
9.	AT33106	[1]	Bracket	(A)
10.	19H3239	[2]	Cap Screw	(A) 3/8" X 1-1/4"
10.	12H304	[2]	Lock Washer	(A) 3/8"
10.	14H812	[2]	Nut	(A) 3/8"
11.	24H1308	[2]	Washer	(A) 13/32" X 1" X 0.134"
12.	U10974	[2]	Bushing	(A)
13.	U13608	[1]	Washer	(A) LATCH
14.	34H336	[1]	Spring Pin	(A) 5/16" X 2-1/4"
15.	AT33105	[1]	Support	(A)
16.	19H1732	[3]	Cap Screw	(A) 3/8" X 1-1/4"
16.	12H304	[3]	Lock Washer	(A) 3/8"
16.	14H812	[3]	Nut	(A) 3/8"
...	AT38040	[1]	Kit	BACKHOE MOUNTED SEAT, VERTICAL HINGED CONVERSION FOR JD300, JD400, JD401-A
