约翰迪尔零件查询93 - BACKHOE MAIN FRAME AND STABILIZERS 93 ( -005700) AND 93 SERIES A (005701-008550) [A12]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 703 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[2]	Stabilizer	(INCLUDES BUSHINGS) ( AU13333 NO LONGER AVAILABLE)
2.	U16057	[2]	Pin Fastener
3.	19H1820	[2]	Cap Screw	HS, SAE 8, 1/2" X 3"
3.	BP12214	[2]	Lock Nut	(SUB FOR U12622) 1/2"
4.	24H1228	[4]	Washer	1-17/32" X 2-1/2" X 0.120"
5.	U16008	[2]	Pin Fastener
6.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
7.	T33536	[4]	Bushing
8.	U16050	[2]	Pin Fastener	ROD GUIDE END
9.	19H3057	[2]	Cap Screw	HS, SAE 8, 1/2" X 2-3/4"
9.	BP12214	[2]	Lock Nut	(SUB FOR U12622)
10.	24H1236	[4]	Washer	13/16" X 2" X 0.149"
11.	U16401	[2]	Bushing
12.	19H3196	[2]	Cap Screw	HS, SAE 8, 3/4" X 4"
12.	12H236	[2]	Lock Washer	3/4"
12.	14H794	[2]	Nut	3/4"
13.	U16055	[2]	Pin	SIDE PLATE
14.	11H277	[2]	Cotter Pin	1/2" X 4"
15.	U16494	[4]	Bushing	HOLLOW
16.	........	[1]	Main Frame	(SUB FOR AU13348) ( AU41212 NO LONGER AVAILABLE)
17.	U10745	[4]	Bushing
18.	19H2993	[2]	Cap Screw	HS, SAE 8, 1/2" X 1-1/2"
18.	24H1341	[2]	Washer	17/32" X 15/16" X 0.060"
18.	12H301	[2]	Lock Washer	1/2"
18.	14H1040	[2]	Nut	1/2", (SUB FOR 14H809)
