约翰迪尔零件查询93 - BACKHOE MAIN FRAME AND STABILIZERS 93 SERIES A (008551- ) [A13]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 468 次

Pos.	Part No	Qty	Parts name	Comments
1.	U16057	[2]	Pin Fastener	ROD END
2.	19H1820	[2]	Cap Screw	HS, SAE 8, 1/2" X 3"
2.	BP12214	[2]	Lock Nut	(SUB FOR U12622) 1/2"
3.	24H1228	[4]	Washer	1-17/32" X 2-1/2" X 0.120"
4.	U16008	[2]	Pin Fastener	PIVOT
5.	11M7073	[4]	Cotter Pin	8 X 63 MM
6.	T33536	[4]	Bushing
7.	........	[2]	Stabilizer	(INCLUDES BUSHINGS) ( AU13333 NO LONGER AVAILABLE)
8.	U10745	[4]	Bushing
9.	U16050	[2]	Pin Fastener	ROD GUIDE ROD
10.	19H3057	[2]	Cap Screw	HS, SAE 8, 1/2" X 2-3/4"
10.	BP12214	[2]	Lock Nut	(SUB FOR U12622) 1/2"
11.	U16401	[2]	Bushing
12.	24H1236	[4]	Washer	13/16" X 2" X 0.149"
13.	19H3196	[2]	Cap Screw	HS, SAE 8, 3/4" X 4"
13.	12H236	[2]	Lock Washer	3/4"
13.	14H794	[2]	Nut	3/4"
14.	U16055	[2]	Pin	SIDE PLATE
15.	11H277	[2]	Cotter Pin	1/2" X 4"
16.	........	[1]	Frame	(INCLUDES BUSHINGS) ( AU41870 NO LONGER AVAILABLE)
17.	U41086	[2]	Bushing
18.	JD7759	[2]	Lubrication Fitting	STRAIGHT, 1/8"
