约翰迪尔零件查询93 - BACKHOE MAIN FRAME AND STABILIZERS FOR 95 AND 95 SERIES A BACKHOES [A15]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 747 次

Pos.	Part No	Qty	Parts name	Comments
1.	U14392	[4]	Bolt	SELF-LOCKING
2.	........	[2]	Stabilizer	BOX, INNER ( AU13460 NO LONGER AVAILABLE)
3.	........	[2]	Wedge	R.H. ( U16110 USE IF AVAILABLE)
4.	19H3196	[2]	Cap Screw	3/4" X 4"
4.	12H236	[2]	Lock Washer	3/4"
4.	14H794	[2]	Nut	3/4"
5.	24H1138	[4]	Washer	1-1/16" X 2" X 0.134"
6.	U16401	[2]	Bushing	SIDE PLATE
7.	U16055	[2]	Pin	SIDE PLATE
8.	11H277	[2]	Cotter Pin	1/2" X 4"
9.	19H2732	[2]	Cap Screw	HS, SAE 8, 3/8" X 2-3/4"
9.	T11234	[2]	Lock Nut	3/8"
10.	U40779	[2]	Pin	STABILIZER, UPPER, (SUB FOR AU13478)
11.	........	[1]	Frame	( AU13469 NO LONGER AVAILABLE)
12.	08H4289	[4]	Cap Screw	HS, SAE 8, 1-1/4" X 4-1/2"
12.	14H824	[4]	Nut	1-1/4"
12.	14H873	[4]	Nut	1-1/4"
13.	U16495	[1]	Bushing
14.	........	[1]	Cylinder Block	SLIDE TOP ( U16113 NO LONGER AVAILABLE)
15.	........	[2]	Wedge	L.H. ( U16111 NO LONGER AVAILABLE)
16.	U16112	[1]	Cylinder Block	SLIDE, BOTTOM
17.	........	[1]	Pin Fastener	( U16493 NO LONGER AVAILABLE)
18.	U16410	[1]	Wrench
19.	34H284	[1]	Spring Pin	3/16" X 1-1/4", (FOR WRENCH)
20.	AU13628	[1]	Handle
21.	19H2855	[2]	Cap Screw	HS, SAE 8, 3/8" X 3-1/4"
21.	T11234	[2]	Lock Nut	3/8"
22.	U16149	[2]	Pin	STABILIZER, LOWER
23.	U10745	[4]	Bushing
24.	........	[1]	Stabilizer	OUTER, L.H. ( AU13755 NO LONGER AVAILABLE)
25.	........	[1]	Stabilizer	OUTER, R.H. ( AU13459 NO LONGER AVAILABLE)
26.	AU13480	[2]	Pin
27.	19H1781	[2]	Cap Screw	HS, SAE 8, 1/2" X 3-1/2"
27.	BP12214	[2]	Lock Nut	(SUB FOR U12622)
28.	AR62151	[2]	Quick Lock Pin	(SUB FOR B11182)
29.	........	[2]	Pin	( U16148 USE IF AVAILABLE)
