约翰迪尔零件查询93 - BACKHOE DIPPERSTICK EXTENSIONS [B01]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 461 次

Pos.	Part No	Qty	Parts name	Comments
1.	U11649	[8]	Washer
2.	11H221	[8]	Cotter Pin	3/8" X 2-1/2"
3.	U16327	[1]	Pin	COUPLER LINK TO TIE LINK
4.	U16167	[2]	Link
5A.	AU11366	[1]	Pin Fastener	DRIVER LILNK TO EXTENSION, ASSEMBLY
5B.	T59458	[1]	Pin Fastener	DRIVER LINK TO EXTENSION, (SUB AU11366)
6.	T67896	[1]	Link	GUIDE (R.H. WHEN USED WITH EXTENTION) (SUB FOR U16168) (ALSO ORDER T67895)
7.	T67895	[1]	Link	GUIDE (L.H. WHEN USED WITH EXTENSION) (SUB FOR U16169) (ALSO ORDER T67896)
8.	........	[1]	Link	TIE, EXTENSION ( AU13582 NO LONGER AVAILABLE)
9A.	AU13556	[1]	Pin Fastener	TIE LINK TO EXTENSION LINK
9B.	T61038	[1]	Pin Fastener	TIE LINK TO EXTENSION LINK, (SUB AU13556)
10.	........	[1]	Pin Fastener	EXTENSION LINKS TO EXTENSION ( U16325 NO LONGER AVAILABLE)
11.	AU13575	[2]	Link
12.	........	[2]	Pin	EXTENSION TO DIPPERSTICK ( U16324 NO LONGER AVAILABLE)
13.	11H260	[2]	Cotter Pin	3/8" X 4"
14.	U11121	[4]	Bushing
15.	U16017	[2]	Bushing
16.	........	[1]	Extension	( AU40006 NO LONGER AVAILABLE) (SUB FOR AU13583)
17.	T59452	[4]	Snap Ring
