Pos.	Part No	Qty	Parts name	Comments
1.	U15846	[1]	Pin	BOOM TO DIPPERSTICK
2.	U11649	[2]	Washer
3.	19H3550	[1]	Cap Screw	HS, SAE 8, 1/2" X 4"
4.	BP12214	[1]	Lock Nut	1/2", (SUB FOR U12622)
5.	T25875	[2]	Bushing	(SUB FOR U41602)
6.	U16017	[2]	Bushing	(SUB FOR U41599)
7.	19H1781	[2]	Cap Screw	HS, SAE 8, 1/2" X 3-1/2"
8.	BP12214	[2]	Lock Nut	1/2", (SUB FOR U12622)
9.	U15822	[AR]	Pin	(1 USED WITH BUCKET CYLINDER) (TWO USED WITH CROWD CYLINDER)
10.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
11.	U11649	[2]	Washer
12.	AU13558	[1]	Pin Fastener	CONTROL LINK TO DIPPERSTICK
13.	U11121	[2]	Bushing
14.	AU43181	[1]	Pivot
15.	U16167	[2]	Link
16.	U42813	[1]	Link	ONE-PIECE
17.	AU13556	[1]	Pin Fastener	CONTROL LINK TO CYLINDER
18.	T67895	[1]	Link	L.H. (USE ONLY WITH DIPPERSTICK EXTENSION) (SUB FOR U16169) (SUB U42813, THIS APPLICATION)
19.	T67896	[1]	Link	R.H. (USE ONLY WITH DIPPERSTICK EXTENSION) (SUB FOR U16168) (SUB U42813, THIS APPLICATION)
20.	........	[1]	Dipperstick	(SUB FOR AU41068) ( AU43182 NO LONGER AVAILABLE)
21.	JD7759	[2]	Lubrication Fitting	STRAIGHT, 1/8"
