约翰迪尔零件查询93 - BACKHOE SUB-FRAME AND MOUNTING PARTS FOR 1010 WHEEL TRACTOR WITH 710 LOADER [C02]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
189 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H2101
|
[2] |
Cap Screw
|
|
| 1. |
12H234
|
[2] |
Lock Washer
|
|
| 1. |
14H1048
|
[2] |
Nut
|
|
| 2. |
24H1138
|
[4] |
Washer
|
|
| 3. |
U10871
|
[2] |
Bushing
|
|
| 4. |
........
|
[1] |
Frame
|
|
| 5. |
08H4042
|
[4] |
Cap Screw
|
|
| 5. |
12H235
|
[4] |
Lock Washer
|
|
| 5. |
14H824
|
[4] |
Nut
|
|
| 6. |
........
|
[2] |
Bracket
|
|
| 7. |
19H1756
|
[4] |
Cap Screw
|
|
| 7. |
12H294
|
[4] |
Lock Washer
|
|
| 8. |
19H3031
|
[4] |
Cap Screw
|
|
| 8. |
12H304
|
[4] |
Lock Washer
|
|
| 8. |
14H812
|
[4] |
Nut
|
|
| 9. |
........
|
[2] |
Strap
|
|
| 10. |
........
|
[2] |
Brace
|
|
| 11. |
........
|
[2] |
Clamp
|
|
| 12. |
11M7032
|
[2] |
Cotter Pin
|
|
