约翰迪尔零件查询93 - BACKHOE SUB-FRAME AND MOUNTING PARTS FOR 2010 AND JD500 WHEEL TRACTOR WITH 700 OR 720 LOADER [C03]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 782 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Frame	( AU13473 NO LONGER AVAILABLE) SUB-FRAME (FOR 95 ONLY)
1.	........	[1]	Frame	( AU40929 NO LONGER AVAILABLE) SUB-FRAME (FOR 93 ONLY) (SUB FOR AU14229)
2.	U13379	[4]	Pin Fastener
3.	11H221	[12]	Cotter Pin	3/8" X 2-1/2"
4.	........	[1]	Support	L.H. ( AU11903 NO LONGER AVAILABLE)
5.	U13380	[2]	Pin Fastener	TIE BAR
6.	08H4197	[4]	Cap Screw	7/8" X 10-3/4", HS, SAE 8, 7/8" X 10-3/4" WITH 2-3/4" THREAD
6.	08H4198	[4]	Cap Screw	7/8" X 11-3/4" JD500 TRACTOR, HS, SAE 8, 7/8" X 11-3/4" WITH 2-3/4" THREAD (BOTTOM HOLES ON 2010 TRACTOR; TOP HOLES ON
7.	........	[2]	Tie Bar	( AU13474 NO LONGER AVAILABLE) (2010 TRACTOR ONLY)
7.	........	[2]	Tie Bar	( AU13475 NO LONGER AVAILABLE) (JD500 TRACTOR ONLY)
8.	19H2700	[2]	Cap Screw	3/8" X 4-1/2", HS, SAE 8, 3/8" X 4-1/2"
8.	12H304	[2]	Lock Washer	3/8"
8.	14H812	[2]	Nut	3/8"
9.	........	[2]	Support	3-POINT HITCH LINK ( AU11897 NO LONGER AVAILABLE)
10.	11M7032	[2]	Cotter Pin	5 X 50 MM
11.	........	[1]	Support	R.H. ( AU11902 NO LONGER AVAILABLE)
