约翰迪尔零件查询93 - BACKHOE SUB-FRAME AND MOUNTING PARTS FOR JD600 WHEEL TRACTOR WITH 740 LOADER OR 648 BULLDOZER WITH 3500 SIDEEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 177 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Frame	(AU14228 NO LONGER AVAILABLE) SUB-FRAME (FOR 93 AND 95 BACKHOES)
2.	U13379	[2]	Pin Fastener	SUPPORT TO SUB-FRAME
3.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
4.	08H4197	[8]	Cap Screw	MACH, HS, SAE 8, 7/8" X 10-3/4"
4.	12H245	[8]	Lock Washer	7/8"
4.	14H836	[8]	Nut	7/8"
5A.	AU14227	[1]	Support	L.H. (SUB AU41293)
5B.	AU41293	[1]	Bracket	L.H.
6A.	AU14226	[1]	Support	R.H.
6B.	AU41292	[1]	Bracket	R.H.
7.	........	[2]	Strap	( U17312 NO LONGER AVAILABLE)
8.	........	[1]	Bracket	BATTERY AND FENDER ( AU14222 NO LONGER AVAILABLE)
9.	........	[1]	Bracket	BATTERY AND FENDER ( AU14223 NO LONGER AVAILABLE)
10.	03H1603	[4]	Bolt	CGE, HS, SAE 8, 5/8" X 2"
10.	12H294	[4]	Lock Washer	5/8"
10.	14H760	[4]	Nut	5/8"
11.	U13380	[2]	Pin Fastener	TIE BAR TO SUB-FRAME
12.	........	[2]	Strap	(FOR 740 LOADER ONLY) ( U17307 NO LONGER AVAILABLE)
13.	........	[2]	Pin Fastener	TIE BAR TO LOADER FRAME ( AU14224 NO LONGER AVAILABLE)
14.	19H2458	[2]	Cap Screw	HS, SAE 8, 3/8" X 3"
14.	T11234	[2]	Lock Nut
15.	........	[2]	Tie Bar	(FOR 648 BULLDOZER ONLY) ( AU40745 NO LONGER AVAILABLE)
16.	U10111	[2]	Pin Fastener	TIE BAR TO BULLDOZER FRAME (FOR 648 BULLDOZER ONLY)
17.	11M7073	[4]	Cotter Pin	8 X 63 MM
