约翰迪尔零件查询93 - BACKHOE SUB-FRAME AND MOUNTING PARTS FOR JD440 AND JD440 SERIES-A SKIDDERS [C06]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 771 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Frame	(A) ( AW12357 NO LONGER AVAILABLE) SUB-FRAME (FOR 93 AND 95 BACKHOES)
2.	........	[1]	Deflector	EXHAUST ( W14699 NO LONGER AVAILABLE)
3.	........	[2]	Pin Fastener	(A) ( W13439 NO LONGER AVAILABLE)
4.	11M7073	[4]	Cotter Pin	(A) 8 X 63 MM
5.	........	[2]	Support	(A) UPPER ( AW12361 NO LONGER AVAILABLE)
6.	19H3107	[12]	Cap Screw	(A) 5/8" X 2-3/4"
6.	12H294	[12]	Lock Washer	(A) 5/8"
6.	14H760	[12]	Nut	(A) 5/8"
7.	........	[2]	Clamp	( AW12980 NO LONGER AVAILABLE) (-067458) DUBUQUE TRACTORS AND (-020334) WELLAND TRACTORS, (SUB FOR AW12362)
7.	........	[2]	Clamp	( AW13360 NO LONGER AVAILABLE) (067459- ) DUBUQUE TRACTORS AND (020335- ) WELLAND TRACTORS (SUB FOR AW12362)
8.	........	[2]	Clamp	( AU12551 NO LONGER AVAILABLE)
9.	19H2728	[8]	Cap Screw	HS, SAE 8, 3/4" X 3"
9.	12H236	[8]	Lock Washer	3/4"
9.	14H794	[8]	Nut	3/4"
10.	........	[2]	Spacer	( W15564 NO LONGER AVAILABLE)
...	........	[1]	Frame	( BW10887 NO LONGER AVAILABLE) SUB-FRAME WITH UPPER SUPPORTS
