约翰迪尔零件查询93 - BACKHOE MOUNTING BRACKETS FOR USE WITH 610 OR 612 BULLDOZER [C07]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
684 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H1708
|
[4] |
Cap Screw
|
|
| 1. |
12H294
|
[4] |
Lock Washer
|
|
| 2. |
........
|
[1] |
Tie Bar
|
|
| 3. |
........
|
[1] |
Bracket
|
|
| 4. |
19H2717
|
[4] |
Cap Screw
|
|
| 4. |
12H236
|
[4] |
Lock Washer
|
|
| 5. |
19H1768
|
[6] |
Cap Screw
|
|
| 5. |
12H236
|
[6] |
Lock Washer
|
|
| 6. |
........
|
[1] |
Base
|
|
| 7. |
19H1707
|
[6] |
Cap Screw
|
|
| 7. |
12H236
|
[6] |
Lock Washer
|
|
| 7. |
14H794
|
[6] |
Nut
|
|
| 8. |
........
|
[1] |
Tie Bar
|
|
| 9. |
........
|
[1] |
Base
|
|
| 10. |
........
|
[1] |
Bracket
|
|
| ... |
BU10118
|
[1] |
Plate
|
|
