约翰迪尔零件查询93 - BACKHOE SUB-FRAME AND MOUNTING PARTS FOR 2010 CRAWLER TRACTOR WITH 626 BULLDOZER [C11]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 657 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Frame	( BU10642 NO LONGER AVAILABLE) SUB-FRAME (INCLUDES ATTACHING HARDWARE)
2.	........	[1]	Tie Bar	L.H. ( AU13567 NO LONGER AVAILABLE)
3.	19H1708	[4]	Cap Screw	HS, SAE 8, 5/8" X 1-3/4"
3.	12H294	[4]	Lock Washer	5/8"
4.	........	[1]	Frame	L.H. ( AU12501 NO LONGER AVAILABLE)
5.	19H2599	[16]	Cap Screw	HS, SAE 8 , 5/8" X 1-3/4"
5.	12H294	[16]	Lock Washer	5/8"
5.	14H760	[16]	Nut	5/8"
6.	........	[1]	Reinforcement	L.H. ( U14381 NO LONGER AVAILABLE)
7.	........	[2]	Reinforcement	BUSSET ( U14379 NO LONGER AVAILABLE)
8.	........	[1]	Gusset	( U14387 NO LONGER AVAILABLE) LIFT FRAME, L.H.
9.	........	[2]	Pin Fastener	( U14578 NO LONGER AVAILABLE)
10.	34H334	[6]	Spring Pin	5/16" X 2"
11.	U10120	[4]	Bushing
12.	........	[1]	Gusset	( U14386 NO LONGER AVAILABLE) LIFT FRAME, R.H.
13.	........	[1]	Reinforcement	R.H. ( U14380 NO LONGER AVAILABLE)
14.	........	[2]	Clamp	( U12584 NO LONGER AVAILABLE) ROUND BAR LOWER
15.	........	[1]	Frame	R.H. ( AU12500 NO LONGER AVAILABLE)
16.	........	[1]	Bar	( AU13566 NO LONGER AVAILABLE) TIE, R.H. (NO LONGER AVAILABLE)
17.	19H3359	[4]	Cap Screw	7/8" X 2", HS, SAE 8, 7/8" X 2"
17.	12H245	[4]	Lock Washer	7/8"
18.	19H1768	[8]	Cap Screw	HS, SAE 8, 3/4" X 2"
18.	12H236	[8]	Lock Washer	3/4"
