| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19H2411 | [10] | Cap Screw | (A) HS, SAE, 8, 3/4" X 2-1/2" |
| 2. | 12H236 | [10] | Lock Washer | (A) 3/4" |
| 3. | U17130 | [2] | Dowel Pin | (A) |
| 4. | AT35575 | [1] | Bracket | R.H. (SUB FOR BU10786) |
| 5. | T10042 | [2] | Screw | (A) |
| 6. | AT35576 | [1] | Bracket | L.H. (SUB FOR BU10787) |
| ... | ........ | [1] | Bracket | ( BU10785 NO LONGER AVAILABLE) INCLUDES ALL PARTS IDENTIFIED BY (A) |
| ... | ........ | [1] | Mounting Parts | (INCLUDES ALL PARTS SHOWN ABOVE) ( AT35005 - NO LONGER AVAILABLE) |
