约翰迪尔零件查询93 - BACKHOE CONTROL VALVE FOR OPEN-CENTER HYDRAULIC SYSTEM 93 ( -005700) AND 95 ( -002450) 93 SERIES AEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 960 次

Pos.	Part No	Qty	Parts name	Comments
1.	U15757	[1]	Bolt	(USE WITH 12H293)
2.	U15107	[1]	Port Plate
3.	U13982	[1]	Fitting
4.	U12547	[1]	O-Ring
5.	U15192	[7]	O-Ring	(C) 1/16" X 7/8" I.D.
6.	U15415	[7]	O-Ring	(C) 1/16" X 1-3/8" I.D.
7.	U11326	[14]	O-Ring	(C) 1/16" X 1-1/8" I.D.
8.	P51212	[14]	O-Ring	(C) 1/16" X 7/16" I.D.
9.	........	[2]	Valve	( AU13402 NO LONGER AVAILABLE) STABILIZER, COMPLETE
10.	........	[1]	Valve	( AU13404 NO LONGER AVAILABLE) CROWD, COMPLETE
11.	........	[1]	Valve	( AU13402 NO LONGER AVAILABLE) BUCKET, COMPLETE
12.	AU40913	[1]	Valve	SWING, COMPLETE
13.	........	[1]	Valve	( AU40914 NO LONGER AVAILABLE) BOOM, COMPLETE
14.	U14404	[1]	Plate
15.	U13946	[2]	Washer	(C) DYNA SEAL
16.	U14401	[2]	Cap Screw
17.	P47908	[1]	O-Ring	(B) 3/32" X 15/16" I.D.
18.	U40727	[1]	Back-Up Ring	(B)
19.	32240	[1]	O-Ring	(B)
20.	U11427	[2]	Plug
21.	U11426	[2]	Orifice	.1405"
...	........	[1]	Valve	( AU41809 NO LONGER AVAILABLE) SIX-SEC. OPEN CTR (INCLUDES RELIEF VALVES) (INCLUDES SPOOL PROTECTIVE COVERS) (SUB FOR AU41053)
...	........	[1]	Valve	( AU41807 NO LONGER AVAILABLE) SIX-SEC. OPEN CTR (INCLUDES RELIEF VALVES) (INCLUDES SPOOL PROTECTIVE COVERS) (SUB FOR AU40779)
...	AU12404	[1]	Kit	REPAIR
...	AT70914	[1]	Seal Kit	O-RING AND SEAL, FOR SECTION ASSEMBLY, (SUB FOR AU12403)
