约翰迪尔零件查询93 - BACKHOE CONTROL VALVE FOR CLOSED-CENTER HYDRAULIC SYSTEM 93 ( -005700) AND 95 ( -002450) [D10]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询93 - BACKHOE CONTROL VALVE FOR CLOSED-CENTER HYDRAULIC SYSTEM 93 ( -005700) AND 95 ( -002450) [D10]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 640 次

Pos.	Part No	Qty	Parts name	Comments
1.	U15757	[1]	Bolt
1.	12H293	[1]	Lock Washer	7/16"
1.	14H807	[1]	Nut	7/16"
2.	U15107	[1]	Port Plate
3.	U13982	[1]	Fitting
4.	U12547	[1]	O-Ring
5.	U15192	[7]	O-Ring	(C) 1/16" X 3/8" I.D.
6.	U15415	[7]	O-Ring	(C) 1/16" X 1-3/8" I.D.
7.	U11326	[14]	O-Ring	(C) 1/16" X 1-1/8" I.D.
8.	P51212	[14]	O-Ring	(C) 1/16" X 7/16" I.D.
9.	AU40387	[2]	Valve	STABILIZER, COMPLETE
10.	........	[1]	Valve	( AU13404 NO LONGER AVAILABLE) CROWD, COMPLETE
11.	........	[1]	Valve	( AU13402 NO LONGER AVAILABLE) BUCKET, COMPLETE
12.	AU40592	[1]	Valve	SWING, COMPLETE
13.	........	[1]	Valve	( AU40361 NO LONGER AVAILABLE) BOOM, COMPLETE
14.	U40604	[1]	Plate
15.	U13946	[2]	Washer	(C) DYNA SEAL
16.	U14401	[2]	Cap Screw
17.	U11427	[1]	Plug
18.	32240	[1]	O-Ring	(B)
19.	U40727	[1]	Back-Up Ring	(B) (SUB FOR U11331)
20.	P47908	[1]	O-Ring	(B)
...	AU40309	[1]	Valve	(A) SIX-SECTION, CLOSED CENTER (INCLUDES RELIEF VALVES) (SUB AU41881)
...	AU12404	[1]	Kit	REPAIR
...	AT70914	[1]	Seal Kit	O-RING AND SEAL, FOR SECTION ASSEMBLY, (SUB FOR AU12403)
