约翰迪尔零件查询93 - BACKHOE SWING VALVE FOR AU40309 AND AU40310 CONTROL VALVES 93 ( -005700) AND 95 ( -002450) [D22]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 520 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap	(SUB FOR U11335)
2.	U11428	[1]	Bolt
3.	N31767	[1]	Washer
4.	U11336	[1]	Spring
5.	U11333	[1]	Bushing
6.	U11345	[1]	Washer
7.	........	[1]		( U13947 NO LONGER AVAILABLE)
8.	32240	[5]	O-Ring	(C) (A)
9.	U13826	[2]	Plug
10.	........	[2]	Ball	(A) ( P50616 NO LONGER AVAILABLE) NYLON, 3/8" DIA.
11.	34H231	[2]	Spring Pin	3/32" X 3/4"
12.	AU40528	[2]	Pressure Relief Valve	10 343 KPA (104 BAR) (1500 PSI)
13.	U40727	[2]	Back-Up Ring	(C) (A) (SUB FOR U11331)
14.	P47908	[2]	O-Ring	(C) (A) 3/32" X 5/16" I.D.
15.	U40729	[1]	Back-Up Ring	(A) 3/32" X 29/32" I.D. (SUB FOR U11342)
16.	AU40593	[1]	Check Valve	(SWING VALVE ONLY)
17.	U16016	[1]	Poppet
18.	U16015	[1]	Spring
19.	U40728	[1]	Back-Up Ring	(A) 1/16" X 5/16" I.D. (SUB FOR U11341)
20.	R27928	[1]	O-Ring	(A) 1/16" X 5/16" I.D.
21.	........	[1]	Housing	(SUB AU40592)
22.	........	[1]	Spool	( U13825 NO LONGER AVAILABLE)
23.	R394R	[2]	O-Ring	(A) 3/32" X 1/2" I.D.
24.	U15414	[2]	Ring	(A)
25.	A3917R	[2]	O-Ring	(A) 1/16" X 3/8" I.D.
26.	........	[1]	Spool	(SUB AU40592)
...	AU40592	[1]	Valve	(SUB AU40913)
...	AU12404	[1]	Kit	REPAIR
...	AU13654	[1]	Kit	O-RING AND SEAL REPAIR
