约翰迪尔零件查询93 - BACKHOE SWING VALVE FOR AU41807 AND AU41809 CONTROL VALVES 93 ( -005700) AND 95 ( -002450) 93 SERIEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 364 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap	(SUB FOR U11335)
2.	U11428	[1]	Bolt
3.	N31767	[1]	Washer
4.	U11336	[1]	Spring
5.	U11333	[1]	Bushing
6.	U11345	[1]	Washer
7.	........	[1]		( U13947 NO LONGER AVAILABLE)
8.	T57247	[2]	O-Ring
9.	U41390	[1]	Plug
10.	R394R	[2]	O-Ring	(A)
11.	U15414	[2]	Ring	(A)
12.	A3917R	[2]	O-Ring	(A)
13.	U41168	[2]	Check Valve
14.	U41170	[2]	Spring
15.	........	[1]	Spool	(SUB AU40913)
16.	U40727	[2]	Back-Up Ring	(C) (A)
17.	P47908	[2]	O-Ring	(C) (A)
18.	........	[1]	Housing	(SUB AU40913)
19.	R27928	[1]	O-Ring	(A)
20.	U40728	[1]	Back-Up Ring	(A)
21.	U16015	[1]	Spring
22.	U16016	[1]	Poppet
23.	AU40593	[1]	Check Valve	(SWING VALVE ONLY)
24.	32240	[1]	O-Ring	(C) (A)
25.	U40729	[1]	Back-Up Ring	(A)
26.	32240	[2]	O-Ring
27.	AU40528	[2]	Pressure Relief Valve	10 343 KPA (104 BAR) (1500 PSI) (WITH AU41809) (93, 95)
27.	AU40815	[2]	Relief Valve	11 204 KPA (112 BAR) (1625 BAR) (WITH AU41807) (93A, 95A)
28.	U41391	[1]	Plug
29.	AU40913	[1]	Valve
...	AU12404	[1]	Kit	REPAIR
...	AU13654	[1]	Kit	O-RING AND SEAL REPAIR
