约翰迪尔零件查询93 - BACKHOE SWING VALVE FOR AU41683 AND AU41808 CONTROL VALVES 93 ( -005700) AND 95 ( -002450) 93 SERIEPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 468 次

Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap	(SUB FOR U11335)
2.	U11428	[1]	Bolt
3.	N31767	[2]	Washer
4.	U11336	[1]	Spring
5.	U41167	[1]	Bushing
6.	U41169	[1]	Bushing
7.	T13119	[2]	O-Ring	(A) 3/32" X 3/4" O.D.
8.	U41162	[1]	Plug
9.	P46051	[2]	O-Ring	(A) 3/32" X 7/16" O.D.
10.	U41170	[2]	Spring
11.	U41168	[2]	Check Valve
12.	........	[1]	Spool	(B) (SUB AT34643)
13.	AU40528	[2]	Pressure Relief Valve	10 343 KPA (104 BAR) (1500 PSI) (IN AU41808)
13.	AU40815	[2]	Relief Valve	11 204 KPA (112 BAR) (1625 PSI) (IN AU41683)
14.	32240	[2]	O-Ring	(C)
15.	U40727	[2]	Back-Up Ring	(C)
16.	P47908	[2]	O-Ring	(C) 3/32" X 5/16" O.D.
17.	........	[1]	Housing	(B) (SUB AT34643)
18.	U41172	[2]	Plunger	ANTI-CAVITATION
19.	N85304	[2]	Spring
20.	R394R	[2]	O-Ring
21.	AN85149	[2]	Fitting
22.	U41163	[1]	Clevis
...	AU40750	[1]	Valve	(B) (SUB AT34643)
...	AU12404	[1]	Kit	(SUB FOR AU40973) REPAIR
...	AU40974	[1]	O-Ring Kit	KIT, REPAIR O-RING
