Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap	(SUB FOR U11335)
2.	U11428	[1]	Bolt
3.	N31767	[1]	Washer
4.	U11336	[1]	Spring
5.	........	[1]	Bushing	( U13358 NO LONGER AVAILABLE)
6.	U11345	[1]	Washer
7.	........	[1]		( U13947 NO LONGER AVAILABLE)
8.	32240	[5]	O-Ring	(A) (C)
9.	AU40529	[1]	Pressure Relief Valve	16 376 KPA (164 BAR) (2375 PSI)
10.	U40727	[2]	Back-Up Ring	(A) (C) (SUB FOR U11331)
11.	P47908	[2]	O-Ring	(A) (C) 3/32" X 15/16" I.D.
12.	........	[1]	Housing	(SUB AU40374)
13.	R27928	[1]	O-Ring	(A) 1/16" X 15/16" I.D.
14.	U40728	[1]	Back-Up Ring	(A) 1/16" X 5/16" I.D. (SUB FOR U11341)
15.	U16015	[1]	Spring
16.	U16016	[1]	Poppet
17.	AU13748	[1]	Check Valve	(INCLUDES U16015 AND U16016)
18.	U40729	[1]	Back-Up Ring	(A) 3/32" X 29/32" I.D. (SUB FOR U11342)
19.	U11425	[1]	Orifice	5.56 MM (.219")
20.	AU40527	[1]	Pressure Relief Valve	20 685 KPA (207 BAR) (3000 PSI)
21.	........	[1]	Spool	(SUB AU40374)
22.	........	[1]	Ball	( P50616 NO LONGER AVAILABLE) NYLON, 3/8" DIA.
23.	A3917R	[1]	O-Ring	1/16" X 3/8" I.D.
24.	U15414	[1]	Ring
25.	R394R	[1]	O-Ring	3/32" X 1/2" I.D.
26.	U13826	[2]	Plug
...	AU40374	[1]	Valve
...	AU13655	[1]	Kit	O-RING AND SEAL REPAIR
...	AU12404	[1]	Kit	REPAIR
