Pos.	Part No	Qty	Parts name	Comments
1.	AU41892	[1]	Cap	(SUB FOR U11335)
2.	U11428	[1]	Bolt
3.	N31767	[1]	Washer
4.	U11336	[1]	Spring
5.	U11333	[1]	Bushing
6.	U11345	[1]	Washer
7.	........	[1]
8.	U11343	[2]	O-Ring	3/32" X 7/8"
9.	AU40529	[1]	Pressure Relief Valve	16 376 KPA (164 BAR) (2375 PSI)
10.	32240	[3]	O-Ring	(A) (C)
11.	U40727	[2]	Back-Up Ring	(A) (C) (SUB FOR U11331)
12.	P47908	[1]	O-Ring	(A) (C) 3/32" X 15/16" I.D.
13.	........	[1]	Spool	(SUB AU40361)
14.	R34802	[1]	O-Ring
15.	U41516	[1]	Ring
16.	AU40992	[1]	Plug	(SUB AU40913)
17.	R27928	[1]	O-Ring	(A) 1/16" X 15/16" I.D.
18.	U40728	[1]	Back-Up Ring	(A) 1/16" X 15/16" I.D. (SUB FOR U11341)
19.	U16015	[1]	Spring
20.	U16016	[1]	Poppet
21.	AU13748	[1]	Check Valve	(INCLUDES U16015 AND U16016)
22.	U40729	[1]	Back-Up Ring	(A) 3/32" X 29/32" I.D. (SUB FOR U11342)
23.	U11425	[1]	Orifice	5.56 MM (.219")
24.	AU40527	[1]	Pressure Relief Valve	20 685 KPA (207 BAR) (3000 PSI)
25.	........	[1]	Housing	(SUB AU40361)
26.	U40605	[1]	Ball	NYLON
27.	34H262	[1]	Spring Pin	5/32" X 3/4"
28.	........	[1]	Pin Fastener	( U40895 NO LONGER AVAILABLE)
29.	........	[1]	Ball	( P50616 NO LONGER AVAILABLE) NYLON, 3/8" DIA.
30.	A3917R	[1]	O-Ring	1/16" X 3/8" I.D.
31.	U15414	[1]	Ring
32.	R394R	[1]	O-Ring	3/32" X 1/2" I.D.
33.	U13826	[1]	Plug
...	........	[1]	Valve	( AU40361 NO LONNGER AVAILABLE)
...	AU13655	[1]	Kit	O-RING AND SEAL REPAIR
...	AU12404	[1]	Kit	REPAIR
