约翰迪尔零件查询93 - BACKHOE BOOM VALVE FOR AU41683 AND AU41808 CONTROL VALVES 93 ( -005700) AND 95 ( -002450) 93 SERIEEPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
541 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AU41892
|
[1] |
Cap
|
|
| 2. |
U11428
|
[1] |
Bolt
|
|
| 3. |
N31767
|
[2] |
Washer
|
|
| 4. |
U11336
|
[1] |
Spring
|
|
| 5. |
U41167
|
[1] |
Bushing
|
|
| 6. |
U41169
|
[1] |
Bushing
|
|
| 7. |
T13119
|
[2] |
O-Ring
|
|
| 8. |
U41162
|
[1] |
Plug
|
|
| 9. |
P46051
|
[2] |
O-Ring
|
|
| 10. |
........
|
[1] |
Spool
|
|
| 11. |
AU40529
|
[1] |
Pressure Relief Valve
|
|
| 12. |
32240
|
[2] |
O-Ring
|
|
| 13. |
U40727
|
[2] |
Back-Up Ring
|
|
| 14. |
P47908
|
[2] |
O-Ring
|
|
| 15. |
AU40527
|
[1] |
Pressure Relief Valve
|
|
| 16. |
........
|
[1] |
Housing
|
|
| 17. |
U41172
|
[1] |
Plunger
|
|
| 18. |
N85304
|
[1] |
Spring
|
|
| 19. |
R394R
|
[1] |
O-Ring
|
|
| 20. |
AN85149
|
[1] |
Fitting
|
|
| 21. |
U41163
|
[1] |
Clevis
|
|
| 22. |
U41170
|
[1] |
Spring
|
|
| 23. |
U41168
|
[1] |
Check Valve
|
|
| ... |
AU40755
|
[1] |
Valve
|
|
| ... |
AU40974
|
[1] |
O-Ring Kit
|
|
| ... |
AU12404
|
[1] |
Kit
|
|
