约翰迪尔零件查询93 - BACKHOE CONTROL LEVERS AND LINKAGE [E09]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 655 次

Pos.	Part No	Qty	Parts name	Comments
1.	U16457	[2]	Handle	(WITH 450 AND 1010 CRAWLER)
2.	M884T	[2]	Grip
3.	14H826	[2]	Nut	1/2"
4.	U10995	[2]	Lever
5.	U16056	[2]	Lever
6.	14H849	[2]	Nut	7/16"
7.	T10342	[2]	Knob
8.	U43703	[4]	Grip
9.	U45111	[2]	Lever	(WITH 450 AND 1010 CRAWLER)
10.	U43214	[2]	Lever
11.	14H760	[2]	Nut	5/8", (SUB FOR U14555, THIS APPLICATION)
12.	34H330	[4]	Spring Pin	5/16" X 1-3/8"
13.	U11001	[2]	Pin
14.	U10897	[2]	Support
15.	U11003	[2]	Pivot
16.	U16011	[2]	Yoke
16.	U41084	[1]	Link
16.	U42825	[2]	Link	FOR CLOSED CENTER VALVE ON 93 SERIES-A (5700-9000), 94 ( -3800), 95 SERIES-A (2450-3700)
16.	U42830	[2]	Link	FOR CLOSED CENTER VALVE ON 93 SERIES-A (9001- ), 94 (3801- ), AND 95 SERIES-A (3701- )
16.	AU44028	[2]	Link	(93A ON JD544 AND JD644)
17.	11M7079	[4]	Cotter Pin	2.500 X 12 MM
18.	U11004	[4]	Pin Fastener
19.	11M7083	[2]	Cotter Pin	3.200 X 50 MM
20.	U16009	[2]	Strap
20.	U41085	[2]	Strap
20.	U42826	[2]	Strap	FOR CLOSED CENTER VALVE ON 93 SERIES-A (5700-9000), 94 ( -3800), 95 SERIES-A (2450-3700)
20.	U42831	[2]	Strap	FOR CLOSED CENTER VALVE ON 93 SERIES-A (9001- ), 94 (3801- ), AND 95 SERIES-A (3701- )
20.	U46738	[2]	Strap	(93A ON JD544 AND JD644)
21.	34H339	[2]	Spring Pin	5/16" X 3/4"
22.	T53976	[2]	Support	(SUB FOR U15803)
23.	14H826	[2]	Nut	1/2"
24.	U43216	[2]	Lever
25.	11M7059	[2]	Cotter Pin	3.200 X 20 MM
