约翰迪尔零件查询93 - BACKHOE LEVER MOUNTING FRAME [E10]EPC John Deere online
广数供应链运营团队, 15 02月, 2025，浏览：
243 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U10895
|
[2] |
Pivot
|
|
| 2. |
34H330
|
[4] |
Spring Pin
|
|
| 3. |
19H2633
|
[4] |
Cap Screw
|
|
| 3. |
24H1305
|
[4] |
Washer
|
|
| 3. |
12H304
|
[4] |
Lock Washer
|
|
| 3. |
14H812
|
[4] |
Nut
|
|
| 4. |
U15804
|
[1] |
Frame
|
|
| 5. |
U16010
|
[2] |
Pin Fastener
|
|
| 6. |
24H1274
|
[6] |
Washer
|
|
| 7. |
U11000
|
[2] |
Pin Fastener
|
|
| 8. |
11M7079
|
[2] |
Cotter Pin
|
|
| 9. |
U11004
|
[2] |
Pin Fastener
|
|
| 10. |
U16011
|
[2] |
Yoke
|
|
| 10. |
U41084
|
[2] |
Link
|
|
| 10. |
U42825
|
[2] |
Link
|
|
| 10. |
U42830
|
[2] |
Link
|
|
| 10. |
AU44028
|
[2] |
Link
|
|
| 11. |
U11003
|
[2] |
Pivot
|
|
