约翰迪尔零件查询93 - BACKHOE TRANSPORT LOCKOUT VALVE FOR JD500 WHEEL LOADER ( -1964) [E13]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 309 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Plug	( AU40227 NO LONGER AVAILABLE)
2.	32240	[1]	O-Ring
3.	U40376	[1]	Spring
4.	........	[1]	Plunger	( U40375 NO LONGER AVAILABLE)
5.	........	[1]	Plunger	( U40382 NO LONGER AVAILABLE)
6.	........	[1]	Plunger	( U40379 NO LONGER AVAILABLE) UPPER
7.	A3917R	[1]	O-Ring
8.	U15414	[1]	Ring
9.	U15414	[1]	Housing	(SUB AU40104)
10.	L1176N	[1]	Snap Ring
11.	........	[1]	Shaft	( U40381 NO LONGER AVAILABLE)
12.	........	[1]	Clip	( U40432 NO LONGER AVAILABLE)
13.	21H1353	[1]	Screw	NO. 6, 3/4"
14.	BP12232	[1]	Lock Nut
15.	U16827	[1]	Dowel Pin
16.	........	[1]	Handle	( U40380 NO LONGER AVAILABLE)
17.	........	[1]	Knob	( U40378 NO LONGER AVAILABLE)
18.	19H1813	[1]	Cap Screw	5/16" X 5/8"
18.	12H303	[1]	Lock Washer	5/16"
19.	19H1897	[1]	Cap Screw	5/16" X 3-3/4"
19.	12H303	[1]	Lock Washer	5/16"
19.	14H611	[1]	Nut	5/16"
20.	........	[1]	Bushing	( U16823 NO LONGER AVAILABLE)
...	........	[1]	Check Valve	( AU40104 NO LONGER AVAILABLE)
