Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Bolt	( U16828 NO LONGER AVAILABLE)
2.	14H611	[2]	Nut	5/16"
3.	U16827	[1]	Dowel Pin
4.	U16822	[1]	Cam
5.	........	[1]	Shaft	( U16821 NO LONGER AVAILABLE)
6.	L1176N	[1]	Snap Ring
7.	12H303	[1]	Lock Washer	5/16"
8.	........	[1]	Housing	(SUB AU13907)
9.	R26906	[3]	O-Ring
10.	AU11753	[1]	Union Fitting
11.	........	[1]	Plunger	( U16825 NO LONGER AVAILABLE)
12.	U15414	[1]	Ring	(A)
13.	A3917R	[1]	O-Ring	(A)
14.	........	[1]	Plunger	( U16826 NO LONGER AVAILABLE)
15.	........	[1]	Spring	( U16824 NO LONGER AVAILABLE)
16.	R375R	[1]	O-Ring	(A)
17.	........	[1]	Plug	( AU13906 NO LONGER AVAILABLE)
18.	........	[1]	Line	( AU13905 N0 LONGER AVAILABLE)
19.	AU11752	[1]	Fitting	90° WITH 0-RING
20.	AU13904	[1]	Adapter
21.	19H1921	[1]	Cap Screw	5/16" X 3-1/4"
22.	........	[1]	Bushing	( U16823 NO LONGER AVAILABLE)
...	........	[1]	Check Valve	( AU13907 NO LONGER AVAILABLE) (LESS ADAPTER UNIONS, TUBE, AND HANDLE)
...	AU13908	[1]	Seal Kit	SEAL REPAIR
